Design, Modeling and Experiments of 3-DOF Electromagnetic Spherical Actuators [Paperback]

A spherical actuator is a novel electric device that can achieve 2/3-DOF rotational motions in a single joint with electric power input. It has advantages such as compact structure, low mass/moment of inertia, fast response and non-singularities within the workspace. It has promising applications in robotics, automobile, manufacturing, medicine and aerospace industry.

This is the first monograph that introduces the research on spherical actuators systematically.? It broadens the scope of actuators from conventional single-axis to multi-axis, which?will help both beginners and researchers to enhance their knowledge on electromagnetic actuators. Generic analytic modeling methods for magnetic field and torque output are developed, which can be applied to the development of other electromagnetic actuators. A parametric design methodology that allows fast analysis?and design of spherical actuators for various applications is proposed. A novel non-contact high-precision 3-DOF spherical motion sensing methodology is developed and evaluated with experiments, which shows that it can achieve one order of magnitude higher precision than conventional methods. The technologies of nondimensionalization and normalization are introduced into magnetic field analysis the first time, and a benchmark database is established for the reference of other researches on spherical actuators.

This volume provides a systematic introduction to the research on spherical actuators.? It broadens the scope of actuators from conventional single- to multi-axes, which allows beginners and researchers alike to enhance their knowledge on electromagnetic actuators.

List of Figures.- ?List of Tables.- ?1 Introduction.- ?1.1 Background and Motivation.- ?1.2 The State of the.- ?1.3 Objective and Scope of the Study.- ?1.4 Book Organization.- ?References.- ?2 Magnetic Field Modelil£3
