Phase-Lock Basics [Hardcover]

Broad-based and hands-on, Phase-Lock Basics, Second Edition is both easy to understand and easy to customize. The text can be used as a theoretical introduction for graduate students or, when used with MATLAB simulation software, the book becomes a virtual laboratory for working professionals who want to improve their understanding of the design process and apply it to the demands of specific situations. This second edition features a large body of new statistical data obtained from simulations and uses available experimental data for confirmation of the simulation results.Preface.

Symbols List and Glossary.

Getting Files from The Wiley Ftp Internet Site.

PART 1. PHASE LOCK WITHOUT NOISE.

1. INTRODUCTION.

1.1 What is a phase-locked loop (PLL)?.

1.2 Why use a phase-locked loop?.

1.3 Scope of This Book.

1.4 Basic Loop.

1.5 Phase Definitions.

1.6 Phase Detector.

1.7 Combined Gain.

1.8 Operating Range.

1.9 Units and the Laplace Variable s.

2. THE BASIC LOOP.

2.1 Steady-State Conditions.

2.2 Classical Analysis.

2.3 Mathematical Block Diagram.

2.4 Bode Plot.

2.5 Note on Phase Reversals.

2.6 Summary of Transient Responses of the First Order Loop.

3. LOOP COMPONENTS.

3.1 Phase Detector.

3.2 Voltage Controlled Oscillator (VCO).

3.3 Loop Filter.

3.3.3.2 Unintended Poles.

3.4 Filter Reference Voltage.

3.5 Note On the Form of the Filter Equation.

3.6 Capacitors in Loop Filters.
