Thyristor-Based FACTS Controllers for Electrical Transmission Systems [Hardcover]

Over the past two decades, static reactive power compensators have evolved into a mature technology and become an integral part of modern electrical power systems. They are one of the key devices in flexible AC transmission systems (FACTS). Coordination of static compensators with other controllable FACTS devices promises not only tremendously enhanced power system controllability, but also the extension of power transfer capability of existing transmission corridors to near their thermal capacities, thus delaying or even curtailing the need to invest in new transmission facilities.

Offering both an in-depth presentation of theoretical concepts and practical applications pertaining to these power compensators, Thyristor-Based FACTS Controllers for Electrical Transmission Systems fills the need for an appropriate text on this emerging technology. Replete with examples and case studies on control design and performance, the book provides an important resource for both students and engineers working in the field.

1.1 Background.

1.2 Electrical Transmission Networks.

1.3 Conventional Control Mechanisms.

1.4 Flexible ac Transmission Systems (FACTS).

1.5 Emerging Transmission Networks.

2. Reactor-Power Control in Electrical Power Transmission Systems.

2.1 Reacrive Power.

2.2 Uncompensated Transmission Lines.

2.3 Passive Compensation.

2.4 Summary.

3. Principles of Conventional Reactive-Power Compensators.

3.1 Introduction.

3.2 Synchronous Condensers.

3.3 The Saturated Reactor (SR).

3.4 The Thyristor-Controlled RlC;
