Troubleshooting Analog Circuits [Paperback]

Based on the author's popular series in EDN Magazine, the book contains a wealth of information on debugging and troubleshooting analog circuits. In this book, you'll find advice on using simple equipment to troubleshoot (would you believe an ordinary AM radio?); step-by-step procedures for analog troubleshooting methods; and generous helpings of the author's unique insights, humor, and philosophy on analog circuits.

• Provides proven methods for troubleshooting analog circuits
• Accompanying disk contains over 60 pre-built Electronics Workbench circuits

Troubleshooting linear circuits - The beginning
hoosing the right equipment
Getting down to the component level
Solving capacitor-based troubles
Preventing material and assembly problems
Solving active-component problems
Identifying transistor troubles
Operational amplifiers - the supreme activators
Quashing spurious oscillations
The analog-digital boundary
Troubleshooting chartsPease attended Mt. Hermon School, and graduated from MIT in 1961 with a BSEE. He worked at Philbrick Researches up to 1975 and designed many OpAmps and Analog Computing Modules.

Pease joined National Semiconductor in 1976. He has designed about 24 analog ICs including power regulators, voltage references, and temp sensors. He has written 65+ magazine articles and holds about 21 US patents. Pease is the self-declared Czar of Bandgaps since 1986. He enjoys hiking and trekking in Nepal, and ferroequinology. His position at NSC is Staff Scientist. He is a Senior Member of the IEEE.

Pease wrote the definitive book, TROUBLESHOOTING ANALOG CIRCUITS, now in its 18th printing. It has been translated into French, German, Dutch, Russian, and Polish. Pease is a columnist in Electronic Design magazine, with over 240 columns published. The column, PEASE PORlce
